# Monday, September 28, 2015¶

## Fixed a bug in atelier¶

Yet another bug in atelier: #553. Congratulations to Hamza who stumbled over this:

The fab bd command failed to call load_fabfile when trying to write the README.rst file. This didn’t disturb anybody until now because I have a ~/.atelier/config.py file (and when you have such a file, all projects are automatically loaded, including load_fabfile.

## Inheritance diagrams¶

While testing above change I rediscovered the Sphinx can generate inheritance diagrams (see 2015-06-29).

Here are some diagrams that might be interesting for Sandeep:

Actors:

Action requests:

Layouts:

## The pp command¶

I discovered that the pp script (installed with atelier is not yet documented. TODO: move /scripts to /atelier/scripts and add it to the API.

## Restarted tim2lino¶

I finally continued to work on #353. This time we have a much more pleasant general structure because accounting has been moved from lino.modlib to lino_cosi.lib.

The new plugin lino_cosi.lib.tim2lino defines no models, no actors and no menu commands, but a fixture (in lino_cosi.lib.tim2lino.fixtures.tim2demo).

This fixture was in lino_presto until now. Next step is to modularize tim2lino. Because e.g. a simple Così customer like apc or fijal is not interested in importing households or calendar entries, but some future customers like spz or myself will want them.

## Release in Eupen¶

For the first time I had the situation that a customer wants to upgrade to the version “which they have been testing during a week” and not to “the latest available version”.

Environment “testlino” becomes the environment for their production site (despite the name), and I created a new environment “a” for their testing site (which is named “testlino”).

From now on I plan to name environments simply “a”, “b”, “c” … because virtual environments cannot be renamed, and because a given environment is normally first used for testing and then for production. I can then easily switching between environments because Lino, Django and Apache activates them using the symbolic link env in their proect directory.

When upgrading their testlino env to the newest development version (which now requires lxml), the first attempt of my trick from Tuesday, September 22, 2015 failed:

$sudo apt-get build-dep lxml [sudo] password for lsaffre: Reading package lists... Done Building dependency tree Reading state information... Done E: You must put some 'source' URIs in your sources.list  So I added a deb-src line to /etc/apt/sources.list and did sudo apt-get update. Now it works: $ sudo apt-get build-dep lxml
Building dependency tree
The following NEW packages will be installed:
debhelper gettext gettext-base intltool-debian libasprintf0c2 libcroco3 libpython-all-dbg libpython-all-dev libpython-dbg libpython2.7-dbg libpython3-all-dbg
libpython3-all-dev libpython3-dbg libpython3-dev libpython3.4 libpython3.4-dbg libpython3.4-dev libunistring0 libxml2-dev libxslt1-dev po-debconf python-all
python-all-dbg python-all-dev python-dbg python-pyrex python2.7-dbg python3-all python3-all-dbg python3-all-dev python3-dbg python3-dev python3-setuptools
python3.4-dbg python3.4-dev
0 upgraded, 35 newly installed, 0 to remove and 75 not upgraded.
Need to get 69.4 MB of archives.
After this operation, 190 MB of additional disk space will be used.
Do you want to continue? [Y/n]


A cool trick: I added an alias to my .bash_aliases:

alias a='. env/bin/activate'


I also invented the trick of having the following line in the settings.py of all sites:

STATIC_ROOT = SITE.project_dir.child(‘env’, ‘collectstatic’).resolve()

I updated the /admin/using page of the Administrator Guide with today’s findings.

## User’s guide, Users’ guide or User guide?¶

The Lino documentation has three “guides”:

• one for application developers
